Flow meter Itron Woltmag M-itron 2.5″
SPESIFIKASI
- Nominal Diameter : 50 – 100 mm
- Starting Flow Rate : 80 – 250 l/h
- Max. Pressure : 20 bar
- Max. Flow Rate : 30 – 150 m3/h
- Max. Temperature : 50 degree C
- Nominal Diameter : 60/65
- Pressure Version : LP HP
- A Standard * : 300
Hubungi :
ITRON INDONESIA
Telp. (021) 8944 5504
HP.+6281211904740
email : sales@wishindo.id
Flow meter Itron Woltmag M-itron 2.5″
SPESIFIKASI
- Nominal Diameter : 50 – 100 mm
- Starting Flow Rate : 80 – 250 l/h
- Max. Pressure : 20 bar
- Max. Flow Rate : 30 – 150 m3/h
- Max. Temperature : 50 degree C
- Nominal Diameter : 60/65
- Pressure Version : LP HP
- A Standard * : 300
DIN : –
B : 150
C : 150
D : 98 95
E : 225 225
F : 323 350
G : 185
H : 381 445
- Weight (meter) : 24.8 28.9
- Weight (mechanism) : 5 5.4
Related products
The most prominent product in the store, which was bought with the highest number - related
WATER METER ITRON Woltex 5 INCH (125 mm)
WATER METER ITRON Woltex 5 INCH (125 mm)
WATER METER ITRON Woltex 5 INCH (125 mm)
WATER METER ITRON Woltex 5 INCH (125 mm)FLOW METER ITRON Woltex 5 INCH (125 mm)
SPESIFICATION
| SIZE | 125 MM (5 INCH) |
| STARTING FLOWRITE | 0.4 M3/H |
| ACCURACY ± 2% FROM | 1.5 M3/H |
| ACCURACY ± 5% FROM | 1.2 M3/H |
| ADMISSIBLE PEAK FLOW (10′ MAX) | 300 M3/H |
| MAX. ADMISSIBLE FLOWRITE (CONTINUOUS) | 200 M3/H |
| HEAD LOSS AT QMAX | 0.23 BAR |
Hubungi :
ITRON INDONESIA
Telp. (021) 8944 5504
HP. +6281211904740
email : sales@wishindo.id
WATER METER ITRON Woltex 3 INCH (80 mm)
WATER METER ITRON Woltex 3 INCH (80 mm)
WATER METER ITRON Woltex 3 INCH (80 mm)
WATER METER ITRON Woltex 3 INCH (80 mm)WATER METER ITRON Woltex 3 INCH DN80
SPESIFICATION
| SIZE | 3 INCH ( 80 MM ) |
| STARTING FLOWRITE | 0.3 M3/H |
| ACCURACY ± 2% | 1.2 M3/H |
| ACCURACY ± 5% | 0.75 M3/H |
| ADMISSIBLE PEAK FLOW (10′ MAX) | 250 M3/H |
| MAX. ADMISSIBLE FLOWRITE (CONTINUOUS) | 120 M3/H |
| HEAD LOSS AT QMAX | 0.55 BAR |
Hubungi :
ITRON INDONESIA
Telp. (021) 8944 5504
HP.+6281211904740
email : sales@wishindo.id
Jual Water Meter Itron 15mm – Water Meter Itron Multimag – Itron Water Meter Multimag TMII
Jual Water Meter Itron 15mm – Water Meter Itron Multimag – Itron Water Meter Multimag TMII
Jual Water Meter Itron 15mm – Water Meter Itron Multimag – Itron Water Meter Multimag TMII
Jual Water Meter Itron 15mm – Water Meter Itron Multimag – Itron Water Meter Multimag TMIIJual water meter ITRON 1/2″ – Water meter ITRON 15mm
Jual water meter Itron size 1/2 inch. Water meter Itron size 1/2 inch type Multimag TMII.
SPESIFICATION
| SIZE | 15mm |
| Type | Multimag |
| Kelas Akurasi/Ratio | R 50 |
| Aliran Mula | <10 L/h |
| Aliran Minimum (Q1) | 32 L/h |
| Aliran transisi (Q2) | 128 L/h |
| Aliran Nominal ( Q3) | 1.6 m³/h |
| Aliran Maksimum (Q4) | 2.0 m³/h |
| Aliran Extra multimag | 3.0 m3/h |
| Temperatur Metrologis maks | 30 ºC |
| Temperatur Kerja maksimum | 50 ºC |
| Tekanan Kerja Maksimum | 16 Bar |
| Pembacaan Maksimum | 9999* m³ |
| Skla Pembacaan Terkcil | 0.02 L |
Hubungi :
ITRON INDONESIA
Telp. (021) 8944 5504
HP. +6281211904740
email : sales@wishindo.id
WATER METER ITRON Multimag 1 INCH (25 mm)
WATER METER ITRON Multimag 1 INCH (25 mm)
WATER METER ITRON Multimag 1 INCH (25 mm)
WATER METER ITRON Multimag 1 INCH (25 mm)FLOW METER ITRON Multimag 1 INCH (25 MM)
SPESIFICATION
| Size | : 25 mm ( 1 Inch ) |
| Type | : Multimag |
| Kelas Akurasi/Ratio | : R 50 |
| Aliran Mula | : <25 L/h |
| Aliran Minimum (Q1) | : 80L/h |
| Aliran transisi (Q2) | : 320 L/h |
| Aliran Nominal ( Q3) | : 4.0 m³/h |
| Aliran Maksimum (Q4) | : 5.0 m³/h |
| Aliran Extra multimag | : 7.0 m3/h |
| Temperatur Metrologis maks | : 30 ºC |
| Temperatur Kerja maksimum | : 50 ºC |
| Tekanan Kerja Maksimum | : 16 Bar |
| Pembacaan Maksimum | : 9999* m³ |
| Skla Pembacaan Terkcil | : 0.02 L |
